Construction Elevator
SC series construction lift
  • SC series construction lift
  • sc200 construction hoist
  • SC Series Construction Elevator

SC Series Construction Elevator

  • Model: SC Series
  • Rated Loading Weight: 2000/2000
  • Rated Lifting Speed: 36m/min
  • Max Lifting Height: 150m
  • Motor Power: 11kw×3sets×2cages
  • Standard: GB/T 5031--2008
(※ Click this button to inquiry)
Share with :
  • Introduction
  • Overview
  • Technical Data
  • Inquiry
■ Overview

Introduction:

GREAT WALL SC series construction lift is a kind of vertical machinery equipment for transportation of personnel and material. With our long-term marketing research and introduction of advanced structure feature, induce technology of domestic and abroad, we research and develop it independently.


It belongs to" gear and rack type" construction lift, and can be achieved steady speed-up and speed-down by this kind of working type. This series products widely used various new technology and technique in production process, and all spare parts are designed by CAXA entity three-dimensional design software, analyze for all important parts by the type of simulating finite element, make all parts have elegant appearance and perfect structure.

These series products have perfect and reliable electrical apparatus and machinery chain safety devices and adopt electrical components and drive mechanism of famous brand in domestic and abroad. Door safety switch, "break rope" protection switch, up and down limit switch, advanced gradual anti-falling safety device, double-rope head sheave and some reliable machinery safety device and some machinery chain switches, overload protection device and calling system of per floor can also be configurated according to the customer's requirement.

This kind of products has some vantages comply with other hoisting equipments: newer design, more steady performance, more reasonable structure, easier operation, more convenient dismounting, larger hoisting height, stronger transportation capacity, working of reliable and safe, without machinery room and wellhole.

This series construction lift can be widely used in high-rise buildings, TV tower, bridge, water tower, electric station and chimney etc. It's also a kind of high efficiency construction elevator and semi-permanent or permanent external elevator, so it can also be used in storehouse and high tower etc some different places, it's indispensable equipment in building operation.

■ Technical Data

Detail Parameters:

ITEM Double Cage
Manufacture License TS241058-2016
Model SC200/200
Rated Loading Weight 2000kg/2000kg
Rated Lifting Speed 36 m/min
Motor Power 11kW×3sets×2cages
Power Supply 380V 60HZ 3Phases
Anti-crash Safety Device SAJ40-1.2
Power Dissipation 11kW×3sets×2cages
Weight of Each Standard Section 150kg
Quantity of Standard Section 48
Net Size of Suspension Cage(L*W*H)(mm) 3000×1500×2550/3000×1300×2550
Size of Standard Section(L*W*H)(mm) 650×650×1508/800×800×1508
MOQ 1set
Delivery Time 12days
Delivery Port Qingdao or Tianjin
