Portable Concrete Mixer
self loading mobile concrete mixer
  • self loading mobile concrete mixer

JZC Series Concrete Mixer

  • Model: JZM series
  • Drive Mode: Gear Drive
  • Capacity: 6-22m3/h
  • Maximum Diameter of Aggregate: 60mm/80mm
  • Power Source: Electric/Diesel Engine
  • Implementation of Standards: GB/T 9142--2000
(※ Click this button to inquiry)
Share with :
  • Introduction
  • Overview
  • Technical Data
  • Inquiry
■ Overview

JZC series climbing bucket feeding concrete mixer , include automatic ones with twin motor and sub-automatic with single motor . Automatic-type’s hopper is driven by conical motor , and hopper up & down , mixing drum’converse & reverse rotary is controlled by electric cabinet , and sub-automatic type’s hopper is operated by handle . Besides, this model can be driven by electric or diesel engine, to meet the requirements of different construction conditions.



It has lots of advantages such as compact structure , smooth working , stable transmission , convenient operation , good mixing quality, high production and high automatic procedures . This series machine may mix plasticity concrete and semi-hard concrete , applies to common construction site , road , bridge , hydropower plant and medium & small scale concrete component factory.

■ Technical Data

JZC series Concrete Mixer Main Technical Parameters:



ITEM JZC250 JZC350 JZC500 JZC750
Discharging Volume(L) 250 350 500 750
Charging Volume(L) 320 560 800 1200
productivity(m3∕h) 6-8 10-14 18-20 20-22
Mixing Drum Rotational Speed(r∕min) 17 14 13 13
Maximum Size Of Aggregate(mm) 60 60 60-80 60-80
Accuracy of Water Supply ≤2% ≤2% ≤2% ≤2%
Power Source Electric/Diesel Engine Electric/Diesel Engine Electric/Diesel Engine Electric/Diesel Engine
Mixing Motor(Kw) 4 5.5 11 15
Lifting Motor(Kw) 4. 4.5 5.5 7.5
Water Pump Motor(Kw) 0.55 0.55 0.75 1.1
Type Specification 6.50-16 6.50-16 7.50-16
Maximum Towing Speed (km/h) 20 14 20
Overall Dimensions(mm) 2260×1990×2750 2766×2140×3000 5226×2200×5460 6116×2056×6060
Weight(Kg) 1300 1950 3100 4200
